CNC Die Sinker EDM Machine
Model: EDMN850CNC
|
|
Parameters UNIT EDMN850CNC
Working Tank (LxWxH) mm 1800 x 1100 x 570
Max. Oil Level mm 350
Table Size (LxW) mm 1150 x 600
Travel Size X mm 800
Y mm 500
Spindle Travel(Z) mm 400
Distance between Spindle
Nose to Work Table Min. mm 350
Max. mm 800
Max. Table Load (Workpiece weight) mm 3000
Max. Spindle Hold (Electrode weight) kg 180
Oil Tank L 750*2
Oil Tank Dimension (LxWxH) mm 2520 x 2000 x 500
Control Method AC / DC (Japan SANYO)
Rated Current A 100
Machine Dimension (LxWxH) mm 2280 x 2470 x 2690
Machine Weight kg 4300
» Current Parameters
Max.
Working Current Best
Speed / Efficiency Best
Electrode Loss Best
Surface Finishing Input Power
100A 750 mm³/ min. <=0.3% 0.2/AC | 0.3/DC 10 KVA
» Accuarcy | Precision (Standard:GB/T 5291.1 - 2001)
Items Resualt
Flatness of the workbench 0.03mm / 1000
X Axis Movement Straightness in Y-X plane 0.015/ 500
in Z-X plane 0.015 / 500
Y Axis Movement Straightness in X-Y plane 0.015 / 500
in Z-Y plane 0.015 / 500
Z- Axis Movement Straightness
(Spindle Perpendicularity ) move on X axis 0.02 / 200
move on Y axis 0.02 / 200
Parallelism of work table move on X axis 0.015 / 300
move on Y axis 0.015 / 300
X-Y Axis Squareness 0.015 / 500
» Configuration | Setup
Resine Sand Casting Machine Body : HT250
Work Table: HT300
X/Y Axis: JANPAN SANYO DC/AC Servo
TAIWAN PMI Linear Guideway
TAIWAN PMI Ball Screw
Z Axis: JANPAN SANYO DC/AC Servo
TAIWAN PMI or HIWIN Linear guideway & Ball screw
JAPAN NSK Bearing
Universal Denmark GRUNDFOS or Taiwan WALRUS Oil Pump
Taiwan Automatic Fire Extinguisher
Taiwan Halogen work lamp
Taiwan Skeet chuck
|
|
|
|
|
