| Digital Display Hydraulic Universal Testing Machine
|
|
Main Structure, Function and Application Range : This series machines are mainly designed for tension, compression, bending and cutting test of metal materials and meet with the requirements of GB/T228-2002"Metallic materials-Tensile testing at room temperature". This machine is also used for compression and bending test of nonmetal materials, such as cement, concrete and so on. Equipping with special auxiliaries, it can be used for mechanical property testing of fastener, wire rope and components. They are ideal testing instrument for project quality testing section, university and college, research institution and industrial and mining enterprise.
1. This machine adopts oil cylinder overhead (underneath) type structure, hydraulic load, hydraulic or manually clamping specimen.
2. The main machine is separated with ergo meter, connected by high-pressure oil pipe and wire,avoiding the influence of ergo meter degree when the specimen is breaking, which makes the value accurate.
3. Testing force indicator dial adopts closed type, which makes scale clear.
4. Loading speed indicator makes operation more convenient. It has three kinds speed: 0.4 rotor/min, 0.8rotor/min and 2rotor/min.
5. Automatic tracer is installed upright of ergo meter shell and can magnify the straining original shape by 2 or 4 times according to the requirements of test. |
|
